Wicket Gate / Linkage / Operating Ring Bearings

Wicket Gate / Linkage / Operating Ring Bearings

ThorPlas-Blue

Box320x190_0000_ThorPlas-Blue wicket gate bearings

ThorPlas-Blue is a homogeneous, self-lubricating polymer bearing capable of withstanding operating pressures up to 45 MPa (6,527 psi) installed in a full-form, interference-fit configuration. It offers low wear rate in non-abrasive environments.

Learn More - ThorPlas-Blue

HPSXL TRAXL

Box320x190_0002_HPSXL TRAXL wicket gate bearing with Thorseal

Homogenous Thordon HPSXL incorporates friction and wear reducing additives throughout its entire molecular structure. Designed for high pressure applications up to 55 MPa (8000 psi) dynamic or 70 MPa (10,000 psi) static peak.

Learn More - HPSXL TRAXL

Documents

Hydro-Turbine Bearings & Seals Brochure PDF, 2.08 MB

Technical Papers

Challenging Edge Loading - A Case for Homogeneous Polymer Bearings for Guidevanes PDF, 3.29 MB (The International Journal on Hydropower & Dams) Issue 6, 2010
Friction and Wear Characteristics of ThorPlas Bearings and Their Applications in Hydro Turbines PDF, 571.16 KB The 2011 Conference Proceedings of HydroVision International, July 19-22, 2011 Sacramento, CA USA
Stick Slip Evaluation of ThorPlas PDF, 2.60 MB
Vattenfall Lulea University - Performance Characteristics of Slow Oscillating Journal Bearings PDF, 2.05 MB

References

Reference articles of Thordon wicket gate, linkage and operating mechanism bearing applications.

Design

The final (fully finished) sizing of a Thordon elastomer or ThorPlas bearing can be determined by using the Thordon Bearing Sizing Calculation Program.

You cannot run the Thordon Bearing Sizing Calculation Program Version 2017, Release 10 without a User Registration Number. Once you have a User Registration Number you can download the Program below and enter it when prompted.

Click here to Request a Bearing Sizing Program User Registration Number

If you have a Bearing Sizing Program User Registration Number, you can download the program here

Videos

Thordon Bearing hydro manager being interviewed about the use of Thordon in hydro turbine applications.

ThorPlas wicket gate bearings are installed in New Zealand.

A video about the machining of a Thordon polymer bearing.
